STANDARD FEATURES
GVWR- 7,000 Lbs.
TANDEM- 3,500 Lb. Axles
Options
1. 2nd Electric Brake Axle
2. 5′ Angle Ramps / Pockets- Side Stored
3. 5′ Angle Ramps- Loose ( Pair )
4. Pipe Top Rail- 2 3/8″ OD
5. Spare Tire & Wheel
6. Spare Mount- Side
7. LED Sealed Rubber Flush Tail Lights
8. 2″ Bull Dog Coupler
9. Tear Drop Fenders- Smooth
10. Diamond Strait Fenders-14G
11. 7,000lb. Drop Leg Jack- Sidewind
12. Adjustable Coupler
13. 2 5/16″ Coupler
14. ST2257515 8ply Tires Bias- Upgrade
15. Spare- ST2257515 8ply Bias/ 15″ Wheel
16. RAMP GATES- 1 1/2 Square Tube x 11G.
A. 4′ Ramp Gate- Spring Assit- 2 Way
B. 5′ Ramp Gate- Spring Assit- 2 Way
C. 4′ Side Ramp Gate- Spring Assist
D. 5′ Side Ramp Gate- Spring Assist
E. Bi Fold Gate- Upgrade ( ILO Strait )
F. Heavy Duty Ramp Gate-Upgrade ( 2 Extra Uprights )
G. 4′ Tractor Ramp Gate- Strait
H. 5′ Tractor Ramp Gate- Strait
17. ATV Side Rail Ramps- 1 1/2″ Square Tube- 11G. & Wrap Tongue
18. 2′ Dove Tail ( 20′ – 14′ Lengths )
19. Diamond Steel Floor 11G.
20. Recess Floor Rings- ( For Steel Floors)
21. Tie Downs & Accessories
22. 2- Idler Axles / No Electric Brakes / ( 2,900lbs – 3,900lbs GVWR )
Components
Axles- 2- 3,500lb. Axles EZ, CAM, 5 on 5 Bolt
One Electric Brake Axle
Springs- 4 leaf Double Eye
Coupler- 2″ A Frame- Ram- (Bull Dog Style )
Jack- 2,000lb Swing Top Wind
Pipe Mount- Center of Tongue
Fenders- Strait Smooth
Treated Wood / Screws- Removeable Floor Cap
Tires- ST2057515 6py Bias
Wheels- 15″ Silver Maud
Stake Pockets- 6 ( 2 Per Side, 2- In Front )
Safety Chains
Lights- Incandescant Square Tail, Front Amber
& Tri Bar Light
Plug- RV 7 Way Round
Breakaway Kit
Metal Tag Bracket
Frame
Tongue- 4″ Channel Wrap
Top Rail- 3x2x3/16″ Angle
Bottom Rail- 3x2x3/16″ Angle
Uprights- 2x2x3/16″ Angle
Crossmembers- 3x2x3/16″ Angle
Ramp Bar- 1x1x1/4″ Angle
Square Tail with Board Slots
Floor Cap- Removeable
1 1/2″ x 1 1/2″ Angle
Frame Options
1. Rub Rail- 2 3/8″ Flat
2. 12″ Center Crossmembers
3. 8″ Channel Main Frame & 6″ Channel Wrap Tongue
4. Strait Bed- No Dove
1. Pipe Top Rail- 2 3/8″ OD
2. 2′ Dove Tail ( 20′ – 14′ Lengths )
3. Diamond Steelfloor- 11G.
4. Recess Floor Rings- In Steel Floors
5. 3″ Channel Crossmembers
6. Expanded Metal / Smooth Metal Sides
For Options Not Listed Contact Dealer
For Options Not Listed Contact Dealer
Available Sizes
1. Bed Lengths- 20′ – 10′
2. Bed Widths (Bed)
A. 83″ ( 82 1/2″ ID )
B. 77″ ( 76 1/2″ ID )
C. 6′ ( 72 1/2″ ID )
D. 5′ ( 48 1/2″ ID )
