Model- S-7LB-T-712
Standard Size- 77” x 12’
GVWR- 7,000lbs
GAWR- 7,000lbs
Empty Weight- Aprox. 1,900lbs
Carrying Capacity- 5,100lbs
Inside Dimensions Between Fenders- 77” ID
Overall Dimension-Outside Fenders- 99” OD
Bed Length- 12’
Components
Axle- 1- 7,000lb 4” Drop Electric Brake- 8 Lug-EZ Lube- Cam
Coupler- 2 5/16 Adjustable Channel
Jack- 7,000lb Drop Leg
Fenders- Smooth Round Single
Tires- ST23580R16E-10ply Radials
Lights- LED Rubber Flush Sealed
Cylinder- 3” x 10” Hydraulic- Cushin/Gravity
Frame
Tongue- 5” Channel Wrap Around- Tilt
Frame- 5 x 3 x 1/4 Angle Iron
Crossmembers- 3” Channel
12” centers
Floor
11g Diamond Plate
Tie Downs
6- D-rings- 1/2″ ( weld on )
4- Stake Pockets- ( 2 per side )
